A Ten-Hour Debugging Session Inside AccountView

A Ten-Hour Debugging Session Inside AccountView: How We Made the PDF Viewer Stable Again

Sometimes software maintenance is a clean, predictable job. And sometimes it is ten hours of staring into Visual FoxPro, legacy ActiveX controls, temporary DBF files, scrambled compiled code, hidden viewers, crashing PDF components, and one very stubborn transport management system that refuses to explain itself.

Yesterday was the second kind.

We spent almost an entire working day investigating a severe stability problem in TransportMaster TMS running inside AccountView. The symptoms were not subtle. After browsing through a few dozen PDF documents, AccountView would start spinning out of control. Temporary FoxPro files would pile up. Internal state appeared to become unstable. In the worst moments, AccountView would no longer start correctly and reported errors such as missing internal objects and corrupted class definitions. In practical terms: the environment became unusable.

The first workaround was painfully simple: delete the files in the user temp directory and try again. That made AccountView start again, but of course that is not a solution. That is the digital equivalent of turning the building power off and back on because one light switch is haunted. Useful in an emergency, not exactly something you want to document as a support procedure.

The Problem

The root of the issue was the old PDF viewing pipeline inside AccountView. AccountView still contained its original hidden PDF viewer, based around legacy components such as PDFVIEW.OCX and HiQPdf.rda. These components were being used in a Visual FoxPro host environment where window ownership, COM callbacks, timers, temp files, docking panels, and ActiveX lifecycle behavior all matter.

Replacing the visible viewer alone was not enough. The old viewer was still being created behind the scenes, still receiving paths, still resizing, still participating in the form lifecycle, and still capable of destabilizing AccountView. That was the important discovery: the new viewer was not a replacement for the old one. It was an additional plugin placed on the form. The original AccountView PDF viewer was hidden, but still alive.

That explained the strange behavior: the new viewer could be stable, but the old hidden viewer could still corrupt the session. It was like fixing the front door while the back door was still wide open.

The Debugging Battle

The session started with an error in AccountView’s PDF-to-TIFF path:

PROCEDURE PDF_MANAGER.WRITE_PDF_AS_TIFF Error number: 1429 Cannot set the operation command. Cannot write. Error 0xE8.

At first, the suspicion was that the HiQPdf stub was incomplete. Logging was added so we could see whether AccountView was calling into functions or command paths that our stub did not yet implement. Then the PDF viewer control was replaced and tested. For a short time it looked stable. Then, after scrolling through enough documents, AccountView started spinning again.

We then inspected the FoxPro temp directories, the loaded procedure stack, the AccountView add-in code, and the new FoxDocViewer integration. The more we looked, the clearer it became that this was not one single bug. It was a chain reaction:

• The old PDF viewer was still active and could sit on top of the new viewer.
• The old viewer was still being resized and controlled by AccountView code.
• The new viewer needed stricter bounds and lifecycle protection inside a FoxPro form.
• Errors during resize, docking, document navigation, or missing files could cascade into AccountView state problems.
• Temporary FoxPro tables and indexes made the symptoms look like database corruption, even when the first trigger was the viewer lifecycle.

Several times we thought the system was stable. Several times AccountView immediately proved otherwise. At one point the application appeared to be “fixed,” only to spin out of control moments later. At another point it no longer started and showed:

Object TMS_LIC is not found.

That was not exactly the motivational message one hopes for after hours of debugging. But it did point us toward the real issue: AccountView’s startup and add-in registration state had become unstable. Once we repaired and reindexed the relevant internal registration/system tables, AccountView started again. That was the first major turning point.

The Actual Fix

The final solution was not one magic line. It was a hardening pass across the whole boundary between AccountView, FoxPro, the old viewer, and the new viewer.

The most important changes were:

• Disabled the dangerous behavior of the old PDF viewer while still leaving enough of its interface intact so AccountView could instantiate it safely.
• Created a stable PDFVIEW.OCX stub that preserves the old COM identity but avoids loading the unstable legacy viewer.
• Created a stable HiQPdf.rda stub that returns a conservative response and drains stdin so AccountView does not block on helper-process communication.
• Hardened the FoxPro-side viewer integration so resize, docking, closing, missing files, and repeated document changes do not destabilize the host.
• Moved the new FoxDocViewer into the correct visual position so it no longer covered AccountView splitters, close buttons, or docking controls.
• Removed test-only path mapping so the client installation uses the real paths stored in AccountView’s document table.
• Cleaned and packaged the final source into two standalone buildable Visual Studio solutions for long-term maintenance.

We also hardened a related ActiveX control, the FileDropArea component, for the same reason. A control that behaves nicely in its own window can still be dangerous inside AccountView. Hosted ActiveX components must be extremely conservative: no unexpected modal dialogs, no unguarded COM callbacks, no unsafe drag/drop assumptions, no resize exceptions, and no lifecycle surprises.

The Result

After the final fixes, the system was tested heavily on Windows 11 Pro with multiple windows, docked and undocked PDF viewer panels, repeated scrolling through documents, missing documents, real PDF paths, resize actions, and normal TransportMaster workflows.

The result: stable like a rock.

No spinning. No temp-file explosion. No hidden viewer fighting for the top layer. No AccountView startup failure. No random corruption-like behavior after scrolling through records. The new FoxDocViewer showed the documents correctly and remained stable through the stress tests.

After roughly ten hours of debugging, testing, breaking, fixing, breaking again, reindexing, recompiling, and occasionally questioning all life choices involving legacy COM controls, we ended with a stable solution and clean source packages.

What We Learned

The biggest lesson is that legacy integration work is not just about replacing the visible component. In a framework like AccountView, hidden controls, old COM identities, form lifecycle hooks, docking managers, timers, and FoxPro temp tables can all continue to participate long after you think you have replaced something.

In other words: if an old component is still registered, still instantiated, and still receiving resize or navigation calls, it is still part of the system. Even if nobody invited it to the meeting.

We also learned that Visual FoxPro applications can be impressively resilient and deeply unforgiving at the same time. One wrong assumption at the COM boundary can look like a database problem. One hidden viewer can make a new viewer look broken. One modal dialog or unguarded callback can destabilize an otherwise correct integration.

Final State

The work has now been cleaned up into proper technical handoff material:

• A clean buildable HiQPdf.rda stub solution.
• A clean buildable PDFVIEW.OCX stub solution.
• A hardened FoxDocViewer integration for AccountView.
• A hardened FileDropArea ActiveX control prepared for future embedding.
• A clear explanation of why the original behavior failed and why the new approach is safer.

It was one of those sessions where every answer created two new questions, and every “this must be it” was followed five minutes later by “no, wait, it is still spinning.” But in the end, the system was stabilized, the root causes were isolated, and the final components are now much better suited to survive inside the AccountView framework.

Not bad for a Friday debugging session that started with a PDF viewer and briefly turned into a full expedition through legacy COM, Visual FoxPro, AccountView internals, and the emotional limits of coffee.
